APC AL HADEED
Armoured Recovery Vehicle (AL-HADEED) is a purpose-built tracked support vehicle designed to recover, repair, and maintain armored vehicles in the field. Equipped with a 20-ton winch, a 3-ton crane, and complete on-board workshop facilities, it ensures rapid maintenance and recovery under combat conditions.
| GENERAL | |
|---|---|
| Length (inches) | 238 |
| Width (inches) | 100 |
| Height (inches) | 119 |
| Combat Weight (Ton) | 15 |
| Personnel Capacity | 5 |
| Type of Armour | Aluminium |
| Ballistic Protection | 7.62 × 51 mm NATO (B-6 Level) |
| Year of Manufacturing | 2004 |
| Year of Trials | 2005 |
| Quantity Produced | Single Prototype |
| POWER PACK | |
|---|---|
| Engine | Detroit Diesel 6V53T |
| Transmission | Allison TX-100-A |
| Gross HP to Combat Weight Ratio | 17.6 HP/Ton |
| PERFORMANCE | |
|---|---|
| Speed (Level Land) | Up to 40 km/h |
| CRANE & RECOVERY SYSTEMS | |
|---|---|
| Crane Lifting Capacity | 3 Ton at 2.2 m |
| Crane Type | Articulated 360° Rotation |
| Winch Pulling Capacity | 20 Ton |
| Hydraulically Operated Outriggers | For Stability |
| ONBOARD EQUIPMENT | |
|---|---|
| Lathe Machine | Available |
| Electric Welding Plant | Available |
| Compressor | Available |
| Grinder | Available |
| Battery Charger | Available |
| Drill Machine | Available |
| Hydraulic Press | Available |
| Gas Welding Plant | Available |
| Bench Vice | Available |
| Generator (5 kW) | Available |
| Tool Box | Available |
